ViewBoard IFP86G1

Genesis Series 86 ft 4K OS-Free Interactive Display

Bring Your Own Device interactive display for versatile use in any scenario

Upgradable framework for enhanced versatility and prolonged longevity

Seamless USB-C plug-and-play connectivity with 65W power charging for convenient presentations

Flexible integration with slot-in PCs, supporting Windows, Linux, and EDLA

Panel Size: 86 ft

Panel Type: TFT LCD Module with DLED Backlight.

Display Area (mm): 1895.04 (H) X 1065.96 (V)

Aspect Ratio: 16:9

Resolution: UHD 3840x2160

Colors: 1.07G

Brightness: 400 nits (typ.)

Contrast Ratio: 4000:1 (typ.) 6000:1 (DCR)

Touch

Type Tech: Ultra Fine Touch Techology (IR Recognition)

Touch Resolution: 32767 — 32767

Touch Point: Windows: 40 points of touch, Android : 20 points of touch

INPUT

HDMI: Rear 2.0 x 3 (HDMI 1 3 Support CEC HDMI 2 Supports CEC ARC)

RGB VGA: x1

Audio: x1

RS232: x1

OPS: x1

OUTPUT

Audio: x1

LAN

RJ45: 1 in 1 out

USB

Type A: Front x3(USB2.0x1, USB3.0x2)

Rear x3(USB3.0x2, 2.0 x1 for FW update)

Type B: Rear x2 (USB 3.0x2)

Type C: x1 ( DP 1.2, Touch, Data Sharing, PD65W, Ethernet 10M 100M)

SPEAKERS

10W x 2

Top Camera Plate

Yes

COMPATIBILITY

HDMI: 3840x2160 60Hz

Special Features

All-in-one USB port: œSmartPort„ USB ft to all channels.

Simple LAN sharing between IFP and slot-in device: 10 100 1000M (USB Type-C 10M 100M, OPS 1000M)

Light Sensor: Yes

Slot in PC: VPC37-W53-G1
