Panel Size: 110 ft
Panel Type: TFT LCD module with DLED backlight
Display Area (mm): 2436.48 (H) 1370.52 (V)
Aspect Ratio: 16:9
Resolution: UHD 3840x2160(Pixels)
Colors: 1.07G colors
Brightness: 400 nits (typ.)
Contrast Ratio: 1200:1(Typ.)
5000:1(Min. with DCR enabled)
Response Time: 8ms
Viewing Angles: H = 178, V = 178 (Typ.)
Backlight Life: 30,000 Hours (Min.)
Surface Treatment: Hardness: 7H, Anti-glare coating
Orientation: Landscape
Platform
Processor: Octa-Core CPU (A734 A534)
RAM: 8GB LPDDR
Storage: 128GB eMMC
Touch
Type Tech: IR Recognition
Touch Resolution: 32767 x 32767
Touch Point: Windows: 40 Android: 20
INPUT
HDMI: x3 (Front x 1 :HDMI 2.0 Rear x 2:HDMI 2.0 x 1, HDMI 2.1 support ARC)
RGB VGA: 1
DisplayPort: 1
Audio: 1 (3.5mm phone jack)
RS232: 1
OPS: X1 OPS Slot
WiFi: X1 Module Slot
OUTPUT
HDMI: 1
Audio: 1 (Earphone Out)
SPDIF: 1
LAN
RJ45: X2 (in x 1ï¼out x 1)
