TP-Link Archer VR300 AC1200 Wireless VDSL ADSL Modem Router 1.2Gbps 867Mbps 5GHz 300Mbps 2.4GHz 3xLAN 1xWAN 1xRJ11 4xAntennas

Parental Controls: manage responsible internet access for your children

Guest Network: provides separate access for guests while securing the home network

Firewall Security: supports DoS, SPI Firewall, IP Addressing Domain Filter, IP MAC Address Binding

Quality of Service: prioritizes network traffic by device or application

IPTV IGMP Proxy Snooping: supports Bridge and Tag VLAN for smooth IPTV application

IPv6: compatible with IPv6 (Internet Protocol version 6)

Multilingual Interface: provides hassle-free configuration in six languages (EN DE IT TR RU PO)

HARDWARE FEATURES

Interface 3 10 100 RJ45 LAN Ports

1 10 100 RJ45 LAN WAN Port

1 RJ11 Port

Button WPS Button

Power On Off Button

Reset Button

Power Supply 12V 1A

VDSL2 Standards ITU G.993.2, Up to 17a pro¬le (POTS)

ITU-T G.993.5 (G.vector)

ITU-T G.998.4 (G.INP)

ADSL Standards Full-rate ANSI T1.413 Issue 2,

ITU-T G.992.1(G.DMT),

ITU-T G.992.2(G.Lite),

ITU-T G.994.1 (G.hs),

ITU-T G.995.1

ADSL2 Standards ITU-T G.992.3 (G.DMT.bis),

ITU-T G.992.4 (G.lite.bis)

ADSL2 Standards ITU-T G.992.5

Dimensions ( W x D x H ) 38529076mm

Antenna Type 4 fixed external antennas

WIRELESS FEATURES

Wireless Standards IEEE 802.11a n ac 5GHz,

IEEE 802.11b g n 2.4GHz

Wireless Speeds 867Mbps at 5GHz

300Mbps at 2.4GHz

Transmit Power 2.4GHz 20dBm(EIRP)

5GHz 23dBm(EIRP)

Wireless Functions Access Point Wireless Bridge, Wireless Enable\Disable, SSID Broadcast Enable\Disable

Wireless Security WEP, WPA WPA2, WPA-PSK WPA-PSK2

encryptions, QSS(WPS)

SOFTWARE FEATURES

Quality of Service ATM QoS, Bandwidth Control

Security NAT Firewall, Access Control, IP and MAC Address Binding

Operating Modes VDSL ADSL Modem Router, Wireless Router

Management Web Based Con¬guration(HTTP), Remote management,

command Line Interface, SSL for TR-069, SNMP v1 2c, Web Based Firmware
