TP-Link TL-SG1008D 8-Port Gigabit Unmanaged Switch Desktop Wall-Mounting Plastic Case Fanless Supports MAC address 802.1p DSCP QoS
8 Gigabit Auto-Negotiation RJ45 ports, Supports Auto MDI MDIX
Green Ethernet technology saves the power up to 80pct
IEEE 802.3x flow control provides reliable data transfer
Plastic case, desktop or wall-mounting design
Plug and play, no configuration required
HARDWARE FEATURES
Standards and Protocols IEEE 802.3i 802.3u 802.3ab 802.3x
Interface 8 10 100 1000Mbps RJ45 Ports
AUTO Negotiation AUTO MDI MDIX
Fan Quantity Fanless
Physical Security Lock No
External Power Supply External Power Adapter (Output: 9VDC 0.6A)
Jumbo Frame 15 KB
Switching Capacity 16 Gbps
Dimensions ( W x D x H ) 7.1 3.5 1.0 in. (180 90 25.5 mm)
Max Power Consumption 4.63W(220V 50Hz)
Max Heat Dissipation 15.80BTU h
SOFTWARE FEATURES
Transfer Method Store and Forward
MAC Address Table 4K
Advanced Functions Green Technology
802.3X Flow Control
Back Pressure
802.1p DSCP QoS (for V7 and later version)
OTHERS
Certification FCC, CE, RoHs
Package Contents 8-Port Gigabit Desktop Switch TL-SG1008D
Power Adapter
Installation Guide
System Requirements
Environment Operating Temperature: 0~40 (32~104)
Storage Temperature: -40~70 (-40~158)
Operating Humidity: 10pct~90pct non-condensing
Storage Humidity: 5pct~90pct non-condensing
Warranty Limited 3-Year Warranty
For further information on our warranty policy please visit: http: www.tp-link.com.au support rma
