TP-Link TL-SG3210XHP-M2 JetStream 8-Port 2.5GBASE-T and 2-Port 10GE SFP L2 Managed Switch with 8-Port PoE

2.5G PoE Ports for WiFi 6: 8— 2.5 Gbps ports smash the gigabit barrier and unlock the full potential of WiFi 6 APs.

10G Lightning-Fast Uplink: 2— 10 Gbps SFP slots enable high-bandwidth connectivity and non-blocking switching capacity.

240 W PoE Budget: 8— 802.3at af-compliant PoE ports with a total power supply of 240 W.

Integrated into Omada SDN: Zero-Touch Provisioning (ZTP), Centralized Cloud Management, and Intelligent Monitoring.

Centralised Management: Cloud access and Omada app for ultra convenience and easy management.

Static Routing: Helps route internal traffic for more efficient use of network resources.

Robust Security Strategies: IP-MAC-Port Binding, ACL, Port Security, DoS Defend, Storm control, DHCP Snooping, 802.1X, Radius Authentication, and more.

Optimise Voice and Video Applications: L2 L3 L4 QoS and IGMP snooping.

HARDWARE FEATURES

Interface 8— 100 1000 2500 Mbps RJ45 Ports

2— 10G SFP Slots

1— RJ45 Console Port

1— Micro-USB Console Port

Fan Quantity 2

Power Supply 100-240 V AC~50 60 Hz

Dimensions ( W x D x H ) 17.3 — 7.1 — 1.7 in (440 — 180 — 44 mm)

Mounting Rack Mountable

Max Power Consumption 17.24 W (110V 60Hz) (no PD connected)

291.49 W (110V 60Hz) (with 240 W PD connected)

Max Heat Dissipation 58.82 BTU h (110 V 60 Hz) (no PD connected)

994.56 BTU h (110 V 60 Hz) (with 240 W PD connected)

PERFORMANCE

Switching Capacity 80 Gbps

Packet Forwarding Rate 59.52 Mpps

MAC Address Table 16 K

Jumbo Frame 9 KB
