SA506 is a M.2 SSD to USB-C adapter that supports both NVMe and SATA protocol based M.2 SSDs. No need to worry about which type of M.2 SSD you have, this adapter converts both SATA and NVMe M.2 SSD to USB-C for easy access on your computer.

This adapter is plug and play and USB powered, no external power needed to operate. USB 3.2 Gen 2 interface for super-fast read and write speed up to 10Gbps. Its an ideal solution for for data migration, drive cloning and data backup. Designed for fast and easy access of M.2 SSD, this cable style adapter makes it easy to swap multiple M.2 SSDs without having to install them into a PC or enclosure.

Features

Dual Protocol support for both NVMe and SATA M.2 SSD

Convert M.2 SSD (M Key or BM Key) to USB-C

USB 3.2 Gen 2 interface up to 10Gbps transfer rate

Cable style adapter for easy swap and access of multiple M.2 SSDs

Supports USAP for faster data transfer speed and maximum performance

Supports TRIM command for improved data writing to extend SSD life

Plug and play, no driver required

LED indicator for power and activity status

Specifications

Model: SA506

Material: ABS Plastic

Interface: USB-C (USB 3.2 Gen 2)

Transfer Rate: NVMe M.2 up to 10Gbps, SATA M.2 up to 6Gbps

Compatible M.2 Type: NVMe M.2, SATA M.2

Compatible M.2 size: 2230 2242 2260 2280 22100

Dimension: 158x37x12mm (LxWxH)

Operation Temperature: 0 - 45 degreeC

Operating System Support: Windows 7 and above, Mac OS 10.8 and above

Package Contents

1x SA506 M.2 SSD to USB-C Adapter

1x User Manual

Important Note

SA506 supports both NVMe and SATA based M.2 SSD (M Key or BM Key), bandwidth will be limited to 6Gbps when using SATA M.2 SSD, as maximum transfer rate of SATA M.2 SSD is 6Gbps
